Product Features
- C/MOS Digital Circuitry
- Time Delays To 170.5 Minutes (3 ranges)
- No First Cycle Effect
- Fully Solid State And Encapsulated
- 0.5% Repeat Accuracy
- Eight Different Modes Of Operation
- Output Rated at 1 Ampere Continuous, 10 Amperes Inrush
- Rocker Type Time Delay Adjustment Switches For
- Positive Switch Settings
- Small Size
- UL/cUL Recognized
Series: BBS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Delay-On-Break | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BCS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Delay On Make. Closed | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BIS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Interval | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BMS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Delay-On-Make | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BOS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Re-Triggerable Single-Shot | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BRS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Recycle | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BSS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Single-Shot | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
Series: BTS
| Mode of Operation | Rating | Output | Form | Time Range | Repeat Accuracy |
|---|---|---|---|---|---|
| Trailing Edge Triggered | 1A | Solid State | SPST | 0.1 - 10,230 Secs. | 0.5% |
